Molex TERMINAL Block, 2WAY 38720-7502

TERMINAL BLOCK, 2WAY---- No. of Positions : 2Ways---- No. of Rows : 1 Row---- Pitch Spacing : 9.53mm---- Product Range : Beau 38720 Series---- Rated Current : 25A---- Rated Voltage : 300V---- SVHC : No SVHC (15-Jan-2018)---- Wire Size AWG Max : 12AWG---- Wire Size AWG Min : 22AWG---- Approval Bodies : CSA, UL---- Colour : Black---- Connector Mounting : PCB Mount---- Connector Type : Terminal Block, Barrier---- Contact Material : Brass---- Contact Plating : Tin over Lead Plated Contacts---- Current Rating : 20A---- Flammability Rating : UL94V-0---- Insulation Resistance : 5000Mohm---- Insulator Material : Thermoplastic---- No. of Rows : 1Rows---- Operating Temperature Max : 110°C---- Voltage Rating VAC : 300V---- Wire Area Size Max : 2.5mm²---- Wire Area Size Min : 0.5mm²---- Withstand Voltage : 10500V---- Working Voltage : 300V
